Dimensions
Width: 29.88" (75.9 cm)Height: 36" (91.4 cm)Depth: 28.88" (73.4 cm)
Shipping Dimensions
Width: 31.5" (80.0 cm)Height: 43.5" (110.5 cm)Depth: 30.56" (77.6 cm)
Weight
215.00 lbs (97.5 kg))
Key Features:
- Baking Drawer
- EasyConvect Conversion System
- Even-Heat True Convection
- Steam Rack
- Five Burners
- 6.5 cu. ft. Oven Capacity
- Aqualift® Self-Cleaning
- FIT Guarantee
- Glass Touch Controls
Baking Drawer
Created for the culinary multitasker, this baking drawer will let you produce several dishes at once. Use the bake, slow cook or keep warm functions to achieve your perfect meal.
EasyConvect Conversion System
Always produce perfectly cooked food with this EasyConvect conversion system. This feature takes the guesswork out of convection cuisine, allowing you to focus on creating culinary delights.
Even-Heat True Convection
Every nook and cranny in your conventional oven will warm up to and stay at the perfect temperature thanks to this Even-Heat true convection system. Consistent warmth within the cavity ensures your meals are just right to serve your family and friends.
Steam Rack
Take your cooking to the next level with this steam rack. Thanks to the additional moisture it provides, your meals will be juicy and mouth-watering.
Five Burners
With burner heat options ranging from 5,000 to 19,000 BTU, preparing delicate sauces and quick-heat stir fries is simple and problem-free. Plus, use the centre-rear burner as a bridge to cook large dishes on your stovetop.
6.5 cu. ft. Oven Capacity
Create the family feast you’ve always dreamed of with this extra-large oven capacity. With 6.5 cu. ft. inside your range, you’ll have plenty of room to roast a turkey or prepare succulent desserts for everyone to enjoy.
AquaLift® Self-Cleaning Technology
Clean your oven without harsh chemicals in only 40 minutes with AquaLift Self-Cleaning Technology. Add water, run the cycle and then wipe away any remaining soils once the cycle is done.
FIT Guarantee
Customize your range to fit your kitchen layout. With KitchenAid’s FIT guarantee, you can match the height of your existing cabinetry using the flexible design elements included with this product.
Glass Touch Controls
Chic and easy to clean, this glass touch display easily allows you to program your oven to cook your meals just the way you want them.
Detailed Specifications:
General Overview:
- Fuel Type: Gas
- Range Type: Slide-In
- Size: 30”
- Oven Capacity: 6.5 cu. ft.
Cooktop Features
- Cooktop Element Style: Gas Burner
- Number of Cooking Elements: Five
- Element Type: Sealed Burner
- Left-Front Element Power: 19,000 BTU
- Left-Rear Element Power: 5,000 BTU
- Right-Front Element Power: 15,000 BTU
- Right-Rear Element Power: 9,200 BTU
- Centre-Rear Element Power: 8,000 BTU
- Cooktop Surface Colour: Co-ordinated
- Cooktop Surface Material: Porcelain-Coated Steel
- Dishwasher Safe
- Grate Finish: Matte
- Grate Material: Cast Iron
- Number of Grates: Two
Oven Features
- Number of Oven Lights: Two
- Light Type: Incandescent
- Automatic Convection Conversion Temperature Adjust
- Power On Indicator Light
- Number of Oven Rack: Three
- Number of Rack Guides: Seven
- Oven Rack Types: One Max Capacity, One Gliding Roll-Out, One Steam Rack
- Aqualift Self-Cleaning
- Hidden Bake Element
- Broiler Location: Top of Oven
- Convection Functions: Bake, Broil, Roast
- Convection Element Type: Single Fan
- Bake Element Power: 18,000 BTU
- Broiler Element Power: 13,000 BTU
- Door Type: Metal and Glass
- Handle Material: Metal
- Handle Type: Stainless Steel Towel Bar Handles
- Features: Baking Drawer Bake, Baking Drawer Keep Warm, Baking Drawer Slow Cook, Clock, Cook Time, Delay Start, Keep Warm, Proofing, Steam Bake, Warm Zone
Dimensions
Range:
- Width: 29.88"
- Height: 36"
- Depth: 26.37"
Shipping:
- Width: 31.5"
- Height: 43.5"
- Depth: 30.56"
- Weight: 235 lb.
